working principle: the winding machine wood drying chamber is saturated steam as heat source and the wet air as medium, automatic or manual control drying medium parameters, using the convection heat transfer of gas medium, mass transfer was carried out on the wood drying of science.

1, the fan starts, will first blowing drying medium radiator, heat exchanger after drying medium temperature, heating medium blowing material, by raising the temperature of the wood, wood moisture to evaporate between began to vaporize.

2, dry indoor air circulation direction is along the height of the pile and lateral movement, motor reversing achieve medium reversible cycle regularly, make of wood drying more evenly.

3, dry indoor humidity of media is to increase humidity by steam injection, with moisture removal and lower humidity.

drying chamber performance characteristics:

1, this product is a domestic famous brand product, make elegant, beautiful appearance, can be made into 20 m3-200 m3 of large, medium and small drying kiln, built in the open air.

2, drying kiln internal adopt aluminum alloy, aluminum and stainless steel materials, corrosion, long service life.

3, 10 cm thick insulation is adopted for the shell and the door, heat preservation is good.

4, the lining board used aluminium flat, with a strong and anti-aging performance of silicon

rubber and aluminum alloy layering fixed, sealed well.

5, drying kiln in normal temperature drying for design standard, for the material and color is small, the influence of the drying quality, drying period is shorter.

6, drying kiln using semi-automatic control, according to dry the benchmark set parameters at each stage in temperature indicating instrument, then the implementation of automatic control.

can be dry needles, hard broadleaf, soft hardwood species of a variety of specifications sheet.
